West Lake Tires AZ534

Search Results

Model: AZ534

Class:

Highlights:

Regional

Description:
- Wide and deep tread enhance driving stability and mileage on all kinds of roads.
- Special tread compound and carcass help to guarantee long tire life and better retread ability.
- Zig-zag main grooves provide superb traction level.

COMPLETE SIZE	Pattern	Tread Depth	Service Index	Standard Rim	Section Width	Overall Diameter	Max Load (S/D)	Cold Inflation Pressure
COMPLETE SIZE	Pattern	32nd	Service Index	Standard Rim	Inch	Inch	lbs	PSI
225/80R17.5-16 TL	AZ534	19.9	123/122L	6.75	8.90	31.69	3415/3305	102
225/90R17.5-16 TL	AZ534	19.9	127/125L	6.75	8.90	33.50	3860/3640	102
245/70R19.5-14 TL	AZ534	20.2	133/131M	7.5	9.76	33.03	4540/4300	110
245/70R19.5-16 TL	AZ534	20.2	136/134M	7.5	9.76	33.03	4940/4675	120
265/70R19.5-16 TL	AZ534	20.2	140/138M	7.5	10.31	34.13	5510/5200	112
265/70R19.5-18 TL	AZ534	20.2	143/141J	7.5	10.31	34.13	6005/5675	123
11R22.5-14 TL	AZ534	21.4	144/142L	8.25	10.98	41.50	6175/5840	105
11R22.5-16 TL	AZ534	21.4	148/145L	8.25	10.98	41.50	6940/6390	123
295/80R22.5-16 TL	AZ534	22.7	150/147M	9	11.73	41.10	7390/6780	120
295/80R22.5-18 TL	AZ534	22.7	152/149M	9	11.73	41.10	7830/7160	131
